NO SPARK - Troubleshooting Tree

Discussion in 'Technical' started by Moespeeds, Mar 29, 2009.

  1. Moespeeds

    Moespeeds Well-Known Member

    Joined:
    Mar 16, 2008
    Messages:
    2,739
    Likes Received:
    111
    Trophy Points:
    48
    Location:
    Cherry Hill, NJ
    My Bike(s):
    2004 Big Dog Chopper, 2011? Redneck Monoshock, 2003 Roadstar Midnight, 2000 Roadstar Custom
    I see alot of posts from guys having electrical breakdowns. I figured I'd post a troubleshooting tree for this type of problem, maybe we could sticky it? Feel free to add or correct:

    Symptom: Bike randomly quits or will not start

    First thing to do is verify that fuel is getting into the carb. Once this is verified, chances are it's electrical.

    If the engine is not cranking:
    Check your battery voltage (12.8)
    Check for an indicator light on your EHC when the RUN button is pressed
    Check your key switch
    Check for 12v going to the small starter wire plugged into the starter solenoid (usually GREEN)

    If you have 12v going to the starter when START is pressed, then you probably have a bad starter or battery.

    To test the starter:

    http://www.bigdogbiker.com/forums/how/11356-how-check-your-starter-solenoid.html

    Open the starter, clean the contacts, and try again.

    If the bike cranks, but won't fire:
    Check for spark. Pull both plugs or use a spare plug. Pull both plug wires, plug one spark plug in, and crank the motor while grounding the threads of the plug on the bike. You should see spark. See the drawing below:

    [​IMG]

    If you have spark, it is most likely a fuel problem.

    If you don't have spark:
    Make sure you have 12v to the coil. The coil should get 12v when you press the RUN button.

    If you have power to the coil, but no spark, check your plugs and plug wires. You may also have a bad coil.

    If you have no power to the coil:
    Check for 12v down at the timing pickup when RUN is pressed. (2005 and up have no timing pickup down there, skip this step)

    If you have power to the timing pickup, but no power at the coil, most likely the pickup is bad. Double check to make sure you have no power to the pickup, and no power at the coil. When you press RUN, the pickup sends 12v to your coil. This is a $30 part at any Harley dealership, but will need to be cut from the harness and soldered back in. If the bike randomly dies, then starts again after cooling down, this usually means a bad pickup. Remove the timing cover, start the bike, and run a hairdryer on the pickup. If the bike dies when it heats up, it's bad.

    If you have no power to the timing pickup, check for a light on the ignition when RUN is pressed, and check to see if the ignition is sending 12v down to the pickup. Also check your EHC. One or the other is likely to be the problem at this point.

    Here is a thread on how to use a multimeter:

    http://www.bigdogbiker.com/forums/technical/11341-night-trains-tip-week-2-a.html

    barhopper likes this.
  2. lee

    lee Well-Known Member

    Joined:
    Nov 5, 2007
    Messages:
    4,818
    Likes Received:
    67
    Trophy Points:
    48
    Location:
    Bristol, England
    My Bike(s):
    2005 Big Dog custom build and Buell custom build
    good post Moe. I would add that when you pull your spark plug leads, the one you are not using should be grounded.

  3. Slider

    Slider Active Member

    Joined:
    Mar 17, 2008
    Messages:
    635
    Likes Received:
    11
    Trophy Points:
    18
    Location:
    Draper, Utah
    My Bike(s):
    "EHC"less 04 107 chopper; 07 RG; 06 Deluxe
    First Name:
    Gary
    Good post Moe. And don't hold the plug or sparks will shoot out your ass.

    jeff hernandez likes this.
  4. Oscar Maldonado

    Calendar Participant

    Joined:
    Jul 19, 2007
    Messages:
    5,831
    Likes Received:
    174
    Trophy Points:
    63
    Location:
    Louisiana
    My Bike(s):
    04' Pitbull
    First Name:
    Oscar
    :lol: :lol: :lol: :lol: :lol: :lol: :lol:

    I've been there - Done that!:roll: :roll: :roll: :roll:

  5. Moespeeds

    Moespeeds Well-Known Member

    Joined:
    Mar 16, 2008
    Messages:
    2,739
    Likes Received:
    111
    Trophy Points:
    48
    Location:
    Cherry Hill, NJ
    My Bike(s):
    2004 Big Dog Chopper, 2011? Redneck Monoshock, 2003 Roadstar Midnight, 2000 Roadstar Custom
    Figured I'd add this from DRBarnhart:

    I've posted this a couple of times...

    How do you test the cam sensor to make sure that is the problem.
    1. Disconnect the cam sensor from the ignition module.
    2. Take out your trusty multimeter and set it to the RX1 scale.
    3. Now while touching the sensor backing plate with the negative meter lead touch the positive meter lead on each of the three wires of the sensor connector (red, black, & green). If you get continuity from the backing plate to any of them the sensor is bad.

    If it passes the first test...
    1. With your meter still at the same settings touch the positive meter lead to the green wire and the negative meter lead to the black wire. If you get an "open" it's good.
    2. Then take the positive meter lead and touch the black sensor wire while touching the negative meter lead to the green wire. In this case an "open" is bad. A reading somewhere around 300 - 750 Kohms is what you're looking for.

    PurpleDog likes this.
  6. Moespeeds

    Moespeeds Well-Known Member

    Joined:
    Mar 16, 2008
    Messages:
    2,739
    Likes Received:
    111
    Trophy Points:
    48
    Location:
    Cherry Hill, NJ
    My Bike(s):
    2004 Big Dog Chopper, 2011? Redneck Monoshock, 2003 Roadstar Midnight, 2000 Roadstar Custom
    Any way we can get a sticky on this?

    Pops and Five Five like this.
  7. Throttle Jockey

    Throttle Jockey Don't Look at my Member!

    Joined:
    Mar 17, 2008
    Messages:
    409
    Likes Received:
    7
    Trophy Points:
    18
    Location:
    Houston Texas area
    My Bike(s):
    2016 Big Dog K9, 81 Superglide
    First Name:
    Robie
    And on a similar note with the spark plugs out you can look closley into the hole and tell if theres gas coming out!

    TJ:roll::roll::roll:

  8. Five Five

    Five Five Well-Known Member

    Joined:
    Jun 14, 2009
    Messages:
    4,002
    Likes Received:
    186
    Trophy Points:
    63
    Location:
    Southern California, The 714,
    My Bike(s):
    2003 pit bull (sold) & 2006 K-9 (bought)
    First Name:
    Bill
    Thanks Moe ....hit you with a little "Rep Power"

    :2thumbs:
    "Five"

  9. MARV

    MARV Well-Known Member

    Joined:
    Aug 14, 2008
    Messages:
    1,937
    Likes Received:
    59
    Trophy Points:
    48
    Location:
    CENTRAL JERSEY
    My Bike(s):
    05 CHOP
    First Name:
    SUL
    thats funny!

    one of the guys with the most talent has minimal rep.

    you go MOE! couple more ground up builds and you might get some respect around here! :roll:

  10. Ray

    Ray Well-Known Member

    Joined:
    Jul 27, 2009
    Messages:
    2,044
    Likes Received:
    418
    Trophy Points:
    83
    My Bike(s):
    2004 Ridgeback
    First Name:
    Ray
    Great post, always appreciated, already knew not to hold sparkplug from experience ! :eek: Watching someone else. like peeing on electric fence!! Talk a friend on mine into doing that ,,:D

    Ray :2thumbs:

    #10 Ray, Jan 7, 2011
    Last edited: Jan 7, 2011
  11. Moespeeds

    Moespeeds Well-Known Member

    Joined:
    Mar 16, 2008
    Messages:
    2,739
    Likes Received:
    111
    Trophy Points:
    48
    Location:
    Cherry Hill, NJ
    My Bike(s):
    2004 Big Dog Chopper, 2011? Redneck Monoshock, 2003 Roadstar Midnight, 2000 Roadstar Custom
    LOL thanks Marv, but my friends have the talent, I just listen well. I don't really know what the rep thing does, but unless I get some kinda prize, I'm not sweating it. Hope all is well up there, we gotta get together for a drink soon. I've been threatening Staffy for months.

  12. DRBarnhart

    DRBarnhart Insert title here...

    Joined:
    Jan 26, 2009
    Messages:
    1,776
    Likes Received:
    108
    Trophy Points:
    63
    Location:
    The Northcoast
    My Bike(s):
    '07 K-9, '90 Fat Boy, & '72 BMW R60/5
    First Name:
    Dennis
    Thanks for the quote Moe! I just copy and paste everytime this quesion gets asked!!! :D
    :cheers:

    Dennis

  13. Moespeeds

    Moespeeds Well-Known Member

    Joined:
    Mar 16, 2008
    Messages:
    2,739
    Likes Received:
    111
    Trophy Points:
    48
    Location:
    Cherry Hill, NJ
    My Bike(s):
    2004 Big Dog Chopper, 2011? Redneck Monoshock, 2003 Roadstar Midnight, 2000 Roadstar Custom
    So again, how do we get a sticky on this? Seems worth it considering so many guys have no spark issues, and I know I've hunted this thread down and hotlinked it a few times.

    Fibersnake likes this.
  14. bearman

    bearman Active Member

    Joined:
    Jan 6, 2012
    Messages:
    831
    Likes Received:
    157
    Trophy Points:
    43
    Location:
    Mobile, AL
    My Bike(s):
    2006 Mastiff, 2007 Sportster
    in the 2007 service manual, page 230, it says
    "the best way to test the ignition module is by troubleshooting to eliminate everyting but the ignition module."

    on the same page it also says
    "the best way to test the ignition coil is by troubleshooting to eliminate everyting but the ignition coil."

    not a boat load of help there, but the paragraph before the first one above, says the ignition module has three LEDs:
    Red comes on when power is applied (key on and run switch pushed, one red LED on on EHC), then blinks when starting and gets signal from crank sensor.
    Yellow and Blue blink when front and rear coil triggers.

    On my 2006,the red LED kinda dimmed and got brighter when trying to crank, but never blinked all the way off (blue and yellow never came on) so I wasn't sure, but with the new crank sensor it blinked all the way of once then the motor roared to life. I was just trying to see if the LED blinked and it cranked. I had to take off the left oil tank cover to see the ignition LEDs.
    I wasn't sure it was the crank sensor so I put the new sensor in just temporary, I left the old one zip tied into the harnes and just unpluged it and removed the sensor, then installed and pluged in the new one.
    I was in the garage so it was easy to see the LEDs on mine, not sure how easy they would be to see in sunlight.

  15. jimizee028

    jimizee028 TRUE COLORS COLLISION

    Joined:
    Aug 26, 2007
    Messages:
    2,547
    Likes Received:
    119
    Trophy Points:
    63
    Location:
    BALTIMORGUE
    My Bike(s):
    big dog chopper 2007
    First Name:
    JIMI
    You Rock Moe.....

  16. RRRUFF

    RRRUFF Well-Known Member

    Joined:
    Jun 20, 2007
    Messages:
    3,021
    Likes Received:
    102
    Trophy Points:
    63
    Location:
    Georgia
    My Bike(s):
    2005 Big Dog Chopper
    :2thumbs::cheers:

  17. mariovitanza

    mariovitanza New Member

    Joined:
    Jun 16, 2012
    Messages:
    2
    Likes Received:
    0
    Trophy Points:
    0
    My Bike(s):
    2004 big dog (chopper)
    I have tried writing to someone about my (wrote for help a few days ago) "Big Dog Chopper" on the Forum and
    have not received any reply. Perhaps I am not writing in the correct area.

    I am having a problem with the bike stalling out seconds after it starts (starts great by the way). Seems the problem started a few months ago, I was having an intermittent "Headlight Problem". Took it to a local bike shop, bike would not stall out for him of course, and headlight came back on by itself.

    Took bike on a 500 mile ride a few weeks ago, (I did take a big chance I know) bike ran great but now the headlight goes out completely (bulb checks out good, even put a new bulb in ---N/G). A few local rides later stalling problem comes back big time. Thats when stalling issue came back.

    The red light on the aluminum box (under seat) where the trouble-shooting plug is located has a red light that I think should be lit when the key is turned in the on position, and/or when the on/off switch on the handlebars are activated, red light only comes on if I hold the the on/off switch and push the start button at the same time, motor cranks, red light comes on and bike starts up great, then in a few seconds the red light goes out and the bike stalls out. I cycle the key on and off press both start buttens again, bike starts, red light light comes on, then stalls out again in a few seconds...........By the way headlight does not work at all now, all other lights/turn singles are working correctly..........HELP !!! HELP !!! HELP !!! What does EHC Module stand for and where is it located........???

  18. bearman

    bearman Active Member

    Joined:
    Jan 6, 2012
    Messages:
    831
    Likes Received:
    157
    Trophy Points:
    43
    Location:
    Mobile, AL
    My Bike(s):
    2006 Mastiff, 2007 Sportster
    the EHC is the Electrical Harness Control and it is the aluminum, box under the seat.
    It sounds like yours is bad, but it could also be the right hand control (specifically the off switch) or the wires going to it, shorting out. Take apart the hand control and trace the wires out and check the connectors. some times just wiggling the connectors on the EHC will fix problems (for a limited time).

  19. Fatboi36

    Fatboi36 New Member

    Joined:
    Jul 21, 2013
    Messages:
    1
    Likes Received:
    0
    Trophy Points:
    0
    My Bike(s):
    Big dog chopper
    Hey guys I need sum major help here getting ready for strugis. I was riding today and hit a nice bump, my big dog chopper shut off, tried to restart but bike won't start it's trying but seems like it has no spark can any1 help

  20. fmcdealer

    fmcdealer New Member

    Joined:
    Sep 8, 2013
    Messages:
    14
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    lampasas texas
    My Bike(s):
    2002 bigdog/pitbull 2009 fat boy
    First Name:
    leroy
    what if you have 12 volts to coil both sides but no spark ran fine when park two weeks later put new battery and starter and now no spark on plugs cranks fine but no spark 2002 bigdog/pitbull 107 just wondering if it could be crank sensor/pickup on right side lower of engine under a little cover looks like a magnet pickup to me
