Custom Cycle Controls and headlight

[KaptinAmerika]

I have TheDeadOne helpin me on this also, thank you Dead, but I thought multiple heads can be, I did say "Can Be", better than one or two so I am throwin this out here.

I have "Custom Cycle Controls" on my ride. If you don't know what they are then look them up:

Climax Controls - Hidden Internal Motorcycle Hand Controls

They incorporate momentary switches for everything but the high low beam switch which is a latch switch built into the left hand grip. Twist it forward for one light level, back for the other.
My issue is they use a relay to deal with the latch switch issue and our BDs use momentary and the EHC to switch between High and Low beam.
I want to get rid of the relay, or not if I have to keep it, and get back to allowing the BDs EHC to control the headlights.
Now I know there are purists on this site that will say "Ditch the EHC", "Less is more" but I have my reasons for sticking with the EHC so all I am really looking for are serious answers and ideas, on this site "Yeah Right".
Any takers?:up:

Update
SO I have found an additional wire that feeds from the Latch switch

I know we have some Ex BD engineers on this site. Can you answer my question? Will holding the ground cause problems with the EHC?



[KaptinAmerika]

Is there another way to push a thread back to the surface?



[Raywood]

Is there another way to push a thread back to the surface?

You just did it!!!



[KaptinAmerika]

You just did it!!!

That was just a retorical question Bro put the flask down and pay attention:roll:

You know it'd be alot more helpful if you coo juz anser tha fugin qvestion



[Raywood]

That was just a retorical question Bro put the flask down and pay attention:roll:

You know it'd be alot more helpful if you coo juz anser tha fugin qvestion

Your too quck for me Kaptn!!! That's why you're the Kaptain and I was just a lowely Master Chief. :lol:

Wish I could answer the question for you but that's way out of my league.



[KaptinAmerika]

I would never say "Lowely" down and dirty maybe but never "Lowely"
I think I have the answer now I just need some verification from someone who knows these EHCs inside out. I would send an email to BD but I already no their just going to say NO because it is a risk issue for them.

By the way what do you think of my new signature.



[Raywood]

I would never say "Lowely" down and dirty maybe but never "Lowely"
I think I have the answer now I just need some verification from someone who knows these EHCs inside out. I would send an email to BD but I already no their just going to say NO because it is a risk issue for them.

By the way what do you think of my new signature.

I was outside earlier and looked up and saw the most beautiful Bald Eagle circling overhead. Awesome site and your signiture reflects the majestic nature of this bird.

:2thumbs::2thumbs:



[KaptinAmerika]

I was outside earlier and looked up and saw the most beautiful Bald Eagle circling overhead. Awesome site and your signiture reflects the majestic nature of this bird.

:2thumbs::2thumbs:

Kinda looks like me when I'm pissed off huh



[KaptinAmerika]

No Ex Bd Engineers on today?
Could use a little input here.



[TheDeadOne]

Try PM'ing NightTrain, he the only one that I know of on here that's "SEEN" the actual EHC schematics. :2thumbs:

dead



[KaptinAmerika]

Try PM'ing NightTrain, he the only one that I know of on here that's "SEEN" the actual EHC schematics. :2thumbs:

dead

Done that just waitin

The shop bypassed the EHC for the air ride and installed a momenary toggle to activate air ride so I think I am going to abandon the grip latch switch, rewire to the BD harness and use the momentary to control the headlight that way I can still use the factory setting for the air ride.

Thanks Dead
