Spherical bolts for the shift linkage thread size?

bdmridgeback

bdmridgeback

Low Down Chop Shop
They are 5/16-24, one end being LH and one RH

Working on some custom water-jet cut shift linkages myself. I just got
the first prototype monday and am working on chrome pricing now.
The first one I have done is a long stretched flame design alot like the
Wicked Image one, but mine is a direct fitment with a spacer kit to make
the shift linkage straight with the primary and move it out from the cylinder.
I should have 4-6 designs when done for all BDM models.

Last edited:
BBChopper

BBChopper

Supports 2 Disabled Vets
Troop Supporter
bdmridgeback said:
They are 5/16-24, one end being LH and one RH

Working on some custom water-jet cut shift linkages myself. I just got
the first prototype monday and am working on chrome pricing now.
The first one I have done is a long stretched flame design alot like the
Wicked Image one, but mine is a direct fitment with a spacer kit to make
the shift linkage straight with the primary and move it out from the cylinder.
I should have 4-6 designs when done for all BDM models.
Click to expand...
Damn Jake I’m glad you answered dat one I’m still working on “Spherical”. I asked da guy across da ditch with the Airboat about it and he tried to send me for some Prop Wash????:roll: :eek: :roll:

Mario77746

Mario77746

Active Member
bdmridgeback said:
They are 5/16-24, one end being LH and one RH

Working on some custom water-jet cut shift linkages myself. I just got
the first prototype monday and am working on chrome pricing now.
The first one I have done is a long stretched flame design alot like the
Wicked Image one, but mine is a direct fitment with a spacer kit to make
the shift linkage straight with the primary and move it out from the cylinder.
I should have 4-6 designs when done for all BDM models.
Click to expand...
Do you have any of the SPHERICAL bolts you can sell me?

BBChopper - Yea, I had to spell check that one first:lol: Didn't know WTF they were called until I started to look for them.....

BBChopper

BBChopper

Supports 2 Disabled Vets
Troop Supporter
Mario77746 said:
Do you have any of the SPHERICAL bolts you can sell me?

BBChopper - Yea, I had to spell check that one first:lol: Didn't know WTF they were called until I started to look for them.....
Click to expand...
Dat sum “Florida Cracker” slang!!:roll: :roll:

WB Cycles

WB Cycles

Well-Known Member
Sorry ... side tracked over here. Here ya go:

BDM160-00275 5/16-24, LH THREAD ROD END (front)- $10.75
BDM160-00274 5/16-24, RH THREAD ROD END (rear) - $10.75
240-000140-09 NUT, 5/16-24, LH, HEX, CLEAR ZINC - $1.00
BDM240-00733 NUT, 5/16-24, HEX, CLEAR ZINC - $1.00​

Just PM me if you decide you want to get them.

WB Cycles

WB Cycles

Well-Known Member
Had a little trouble finding the listing. Looked for "donut" bolts..... "round end thingie" bolts ..... small "tennis racket looking" bolts ..... just got lucky finding them. :roll: :2thumbs:

Mario77746

Mario77746

Active Member
BBChopper said:
Ahyite Tank ya, I'm back woods but chit diz waz funkin me up all day!!!:bang: :eek: :roll:
SEFREAKARIAL BOLTZ....
Itz all good!
Click to expand...
Dude, your freakin crackin me up!!!:roll: :roll: :roll:

So that's what they are called:cheers: The first time I read it I thought it was Hemi like the Dodge Hemi...... Who the fuck named them Heim Joints. Look at the better options we listed above:roll: :roll: :roll:

G

Gas Man

Cool isn't cheap
Calendar Participant
OK... I was totally confused as to what you were talking about..

Don't get the BDM ones... get landmark heim joints... mucho better!!!! :zz2cents:
