I also used the longer bolts in the heads but I took a stainless washer an cut it down so it would just fit in those holes, I also made the camel toe bolt 5/16, red loctite on it all! they have'nt moved at all!!
Top motor mount/coil cover
- Thread starter Raywood
- Start date
erldawg
Guru
Your reading too much into it. Look in your service manual section 2 the top bolt S/B a 1/2"-20 x 1 3/4" not a 5/8"-20 x 1 3/4"
francoblay1
The Spaniard
As per this post...
http://www.bigdogbiker.com/forums/help-wanted/34780-bolts-needed.html
Can someone please tell me the right size for these bolts... 1.5" long... what about the thread?
I am going to order online from Afghanistan so on my next R&R I will be able to fix the Dog.
Thanks gents.
http://www.bigdogbiker.com/forums/help-wanted/34780-bolts-needed.html
Can someone please tell me the right size for these bolts... 1.5" long... what about the thread?
I am going to order online from Afghanistan so on my next R&R I will be able to fix the Dog.
Thanks gents.
Nukeranger
Nukeranger
It should be 1/2 inch 20 tpi.
francoblay1
The Spaniard
Thanks Nuke,
The webpage is giving me these thre options... which one should I order?
Your help is very much appreciated.
Coarse (standard) thread
1/4"-20
5/16"-18
3/8"-16
Socket cap (smooth), Chrome plated grade 8 steel - Bolt Depot
francoblay1
The Spaniard
Gents,
Are these the right ones??? Socket cap (smooth), Chrome plated grade 8 steel, 1/4"-20 x 1-1/2" - Bolt Depot
Thanks.
Are these the right ones??? Socket cap (smooth), Chrome plated grade 8 steel, 1/4"-20 x 1-1/2" - Bolt Depot
Thanks.
Nukeranger
Nukeranger
I am so sorry, I gave you the upper mounting bolt from the service manual. I just measured my coil cover chrome bolt and it was 3/8"-16 and an inch long as described in the service manual. I also measured the depth and 1.5 inch depth with a washer will work. I think I will order some longer ones myself.
francoblay1
The Spaniard
Thanks Haw,
so.... this ones Socket cap (smooth), Chrome plated grade 8 steel, 3/8"-16 x 1-1/2" - Bolt Depot are this ones the correct ones?
Cheers
Nukeranger
Nukeranger
That picture bothers me because it doesn't say or show threads the entire length. I just went to my local ACE Hardware store and picked up 6 Socket Cap smooth 3/8"-16 1-1/2 inches long as shown below with lock washers. I'll let you know how they fit once I get a chance to remove my ignition cover. I need to replace the ignition switch connector under the cover with a DTM plug.
Update: I put a 1-1/2 in the front and back like Gas Man did above except I used a chrome lock washer.
Last edited:
francoblay1
The Spaniard
rgr that, I will wait for your feedback before ordering (I´d hate to order the wrong ones :bangThat picture bothers me because it doesn't say or show threads the entire length. I just went to my local ACE Hardware store and picked up 6 Socket Cap smooth 3/8"-16 1-1/2 inches long as shown below with lock washers. I'll let you know how they fit once I get a chance to remove my ignition cover. I need to replace the ignition switch connector under the cover with a DTM plug.
Just PM me if you like.
Thanks Haw.
francoblay1
The Spaniard
Huw,That picture bothers me because it doesn't say or show threads the entire length. I just went to my local ACE Hardware store and picked up 6 Socket Cap smooth 3/8"-16 1-1/2 inches long as shown below with lock washers. I'll let you know how they fit once I get a chance to remove my ignition cover. I need to replace the ignition switch connector under the cover with a DTM plug.
Update: I put a 1-1/2 in the front and back like Gas Man did above except I used a chrome lock washer.
I´ve received the bolts today. Thanks a lot! :2thumbs:
Some Rep Points for you too :up:
Franco.
